Medium Flow Pressure Regulators
Our medium-flow pressure regulators are primarily for use on gas service with diaphragm-sensed elements to control up to 10bar (145psi) and piston-sensed elements covering higher requirements up to 414bar (6,000psi). Available in 316SS and brass with the option of parts degreased to G93 for use on oxygen service. Port sizes from 1/2" to 1".
ENQUIRE |  |
|
Medium Flow Pressure Regulators |
 DF1034Dual-Flow Pressure Regulator: Liquid / Piston / Self-Venting / Max. Inlet: 1,034 bar (15,000 psi) / Max. Outlet: 1,034 bar (15,000 psi) / Cv 1.5 (primary) & 0.06 (secondary) |
MF101Medium-Flow Pressure Regulator: Gas or Liquid / Piston / Cone Seat / Self-Venting or Non-Venting / Max. Inlet: 414 bar (6,000 psi) / Max. Outlet: 40 bar (580 psi) / Cv 0.5 |
MF210Medium-Flow Pressure Regulator: Gas / PTFE-Lined Diaphragm / Non-Venting / Max. Inlet: 40 bar (580 psi) / Max. Outlet: 10 bar (145 psi) / Cv 1.8 |
MF230Medium-Flow Pressure Regulator: Gas or Liquid / Elastomeric Diaphragm / Non-Venting / Max. Inlet: 230 bar (3,350 psi) / Max. Outlet: 10 bar (145 psi) / Cv 1.0 |
MF231Medium-Flow Pressure Regulator: Gas / Piston / Non-Venting / Max. Inlet: 230 bar (3,350 psi) / Max. Outlet: 100 bar (1,450 psi) / Cv 1.0 |
MF300TMedium-Flow Tracking Pressure Regulator: Gas or Liquid / Piston / Self-Venting / Max. Inlet: 300 bar (4,350 psi) / Max. Spring Adjust. Outlet: 25 bar (360 psi) / Cv 2.0 |
MF301Medium-Flow Pressure Regulator: Gas or Liquid / Piston / Non- or Self-Venting / Max. Inlet: 300 bar (4,350 psi) / Max. Outlet: 300 bar (4,350 psi) / Cv 2.0 |
MF400Medium-Flow Pressure Regulator: Gas or Liquid / Diaphragm / Non-Venting / Max. Inlet: 400 bar (5,800 psi) / Max. Outlet: 10 bar (145 psi) / Cv 2.0 |
MF401Medium-Flow Pressure Regulator: Gas or Liquid / Piston / Non-Venting / Max. Inlet: 400 bar (5,800 psi) / Max. Outlet: 400 bar (5,800 psi) / Cv 2.0 |
|
